iQ300, Front-loading washing machine, 8 kg, 1400 rpm SIEMENS WM14N228FR
Spare parts are available for purchase: https://shop.euras.com/default.php?&g7=2845040N
Washing machine installation, loading, drum, and spin cycle:
Feet :
Device with adjustable feet
Opening type:
Window
Immediate access (as long as the washing machine allows it)
Hinge position: left
Spin speed:
Maximum of 1400 rpm
Variable speed spin cycle (manually)
Other information
drum and tub:
Spin speed of the Eco 40-60 program at nominal capacity: 1330 rpm
Other engine information:
Motor type: Induction
Washing machine settings and programs:
Temperature variation:
Yes (manually adjustable thermostat)
Color program:
Dark colors (max. 40°)
Textile programs:
Shirts (max. 60°) • Cotton (max. 90°) • Delicates / silk (max. 40°) • Wool / hand wash (max. 40°) • Lingerie (max. 40°) • Synthetics (max. 60°)
Quick programs:
Express 15 / 30 min (max. 40°) • Fast mix (max. 60°)
Special programs:
Hygiene (max. 60°) • Outdoor / Waterproofing (max. 40°)
Cycle programs:
Spin/drain • Drum cleaning • Rinse
Washing machine comfort features:
Comfort features:
Delayed end up to 24 hours
Electronic weighing
Other "comfort" information:
Cycle counter
Display:
LCD/Digital Display
Basic settings:
- Key volume and end signal
- Drum cleaning reminder
- Program counter
Indicators and warning lights:
List of available indicators:
- Time remaining indicator
- Visual and audible end-of-cycle indicator
- Water supply indicator
- Locked door indicator
Loading recommendation
Drum cleaning reminder
Keys:
Touch-sensitive buttons
Other washing machine features and safety mechanisms:
Laundry tub:
3 compartments
Other equipment:
Anti-
vibration design • Visual error diagnosis
Anti-vibration design
Drain pump filter accessible from the front
Security:
Security opening
Child safety
Anti-overflow
Anti-imbalance Anti-foam
Dimensions and weight of the washing machine:
Dimensions when unpacked:
848 x 598 x 550 mm (H x W x D)
Adjustable height:
on 12 mm
Water inlet hose length:
150 cm
Water drain hose length:
150 cm
Power cable length:
160 cm
More information:
Depth including porthole: 600 mm
Washing machine performance and energy consumption (since 2021):
Cost of washing for 100 cycles:
€28.07 (approximate)
• Energy class Washing/Spinning:
C (Index: 67.9)
• Spin efficiency class:
B
• Residual moisture content:
53.4%
• Washing efficiency index:
1.031
• Electric:
62 kWh / 100 cycles
• Water :
47 Liters / 1 Cycle
Cycle duration:
3 hours 26 minutes
Noise class during spin cycle:
75 dB(A) re 1 pW
Information:
Important information regarding these measures since 2021:
- All measures are now based on the use of a program called "eco 40-60" (or equivalent).
- Electricity and water consumption use the same program, but are weighted averages of combinations of full and partial loads.
Other information on washing machine consumption:
Power consumption in standby mode (left on):
0.5 W
Consumption during delayed mode:
3.8 W
Power consumption in off mode:
0.12 W
Electrical information:
220-240 V • 50 Hz • 10 A
More information:
Connection power: 2300 W
Washing machine lifespan:
Miscellaneous information about the washing machine:
Colors:
Chassis: White
Headband: White
Porthole: Black
Reference (EAN and/or UPC):
WM14N228FR (4242003919767)
