For pizzerias, pastry shops, crêperies, institutions...
Spare parts available for purchase: Yes
https://shop.euras.com/anfrage.php?g7=2845040N
-
Motor : thermal protection
Single-phase
220-240 V - 50/60 Hz - 600 W
100-120 V - 50/60 Hz - 650 W
Three-phase
220-240 V - 50 Hz - 510 W
380 V - 50 Hz - 510 W
1500 RPM (50 Hz) - 1800 RPM (60 Hz)
- Materials: Stainless steel and aluminum alloy.
-
Sheet metal entirely made of stainless steel .
-
Weight :
Net weight: 31 kg (68 lbs)
Gross weight: 34.5 kg (75 lbs)
-
Dimensions / Packaging (box) :
- Height: 580 mm (23") / 650 mm (25.6")
- Width: 360 mm (14") / 390 mm (15.4")
- Depth: 530 mm (21") / 605 mm (23.8")
Packed volume: 0.153 m³ / 5.4 cubic feet
-
Security :
- Protection by safety grille which causes the motor to stop if opened.
- Safety measures in the presence of the tank.
- Emergency stop button
- Undervoltage protection
- Restart using the "ON" button
-
Tank : 10 liters removable, made of 18/10 stainless steel.
- Up and down system: quick tank locking by rotating 1/4 turn.
- 8-position speed variator
- Planetary speed: 50 to 150 rpm (50Hz).
- Tool speed: 180 to 540 rpm (50Hz).
-
Standards :
- Versions 27 (220-240V - 50/60Hz): CE, RoHS.
- 27V1 versions (100-120V - 50/60Hz): CE, UL, RoHS.
PDF specifications sheet
PDF user manual
Exploded View 1 GIF Exploded View 2 GIF
